🖥️ Lenovo ThinkVision T23i-30 – Full Technical Specifications
| Category | Specification |
|---|---|
| Product Name | Lenovo ThinkVision T23i-30 |
| Display Size | 23.0 inches |
| Resolution | Full HD (1920 x 1080) |
| Panel Type | In-Plane Switching (IPS) |
| Backlight | WLED |
| Aspect Ratio | 16:9 |
| Brightness | 250 cd/m² (nits) |
| Contrast Ratio | 1000:1 (static), 3,000,000:1 (dynamic) |
| Color Gamut | 72% NTSC |
| Color Depth | 8-bit (6-bit + FRC) |
| Color Support | 16.7 Million Colors |
| Pixel Pitch | 0.265 x 0.265 mm |
| PPI (DPI) | 96 dpi |
| Response Time | 4 ms (Extreme), 6 ms (Normal), 14 ms (Off) |
| Refresh Rate | 60Hz |
| Viewing Angle | 178° (Horizontal) / 178° (Vertical) |
| Screen Coating | Anti-glare |
| Ergonomics | Tilt (-5° to +23.5°), Swivel (±45°), Pivot (±90°), Height adjustment (up to 155mm) |
| Bezel Width | Side: 2mm / Top: 2mm / Bottom: 17.3mm |
| Color | Raven Black |
🔌 Connectivity Ports
| Port Type | Quantity |
|---|---|
| HDMI 1.4 | 1 |
| DisplayPort 1.2 | 1 |
| VGA | 1 |
| USB-B 3.2 Gen 1 | 1 (Upstream) |
| USB 3.2 Gen 1 | 4 (Downstream, including 1x BC 1.2) |
| Audio-out (3.5mm) | 1 |
| Power Connector | 1 |
⚡ Power & Energy
| Feature | Value |
|---|---|
| Power Consumption (Typical) | 15W |
| Power Consumption (Max) | 48W |
| Power in Sleep Mode | <0.5W |
| Power in Switch-off Mode | <0.3W |
| Energy Star Power On | 11.88W |
| Energy Star TEC | 37.05 kWh |
| Power Supply Type | Internal |
| Voltage Range | AC 90 to 264 V (50–60Hz) |
🧩 Design & Dimensions
| Model | Dimensions (W x D x H) | Weight |
|---|---|---|
| Head Only | 522 x 46.4 x 313.1 mm (20.55 x 1.83 x 12.33 in) | 3.2 kg (7.05 lbs) |
| With Stand (Highest) | 522 x 199.7 x 493.8 mm (20.55 x 7.86 x 19.44 in) | 5.2 kg (11.46 lbs) |
| With Stand (Lowest) | 522 x 199.7 x 338.8 mm (20.55 x 7.86 x 13.34 in) | |
| Packaging Dimensions | 592 x 150 x 421 mm (23.31 x 5.91 x 16.57 in) | 7.3 kg (16.09 lbs) |
| VESA Mount | 100mm x 100mm supported |
🔒 Security & Compliance
| Feature | Details |
|---|---|
| Physical Lock Support | Kensington® Security Slot™ |
| Certifications | ENERGY STAR®, EPEAT™ Gold, RoHS, TCO 9.0, Eyesafe® Certified 2.0, TÜV Rheinland® Eye Comfort, Flicker Free, Low Blue Light |
| Blue Light Technology | Natural Low Blue Light (Hardware Solution) |
📦 What’s in the Box
-
Monitor with Stand
-
1x HDMI Cable (1.8m)
-
1x USB-A to USB-B Cable (1.8m)
-
1x Power Cable (1.8m)
-
Quick Setup Guide
-
Warranty Booklet
🛠️ Software & Compatibility
| OS Compatibility | Supported |
|---|---|
| Windows® 10 / 11 | Yes |
| Mac OS | Yes (ThinkColour software support varies) |
| Lenovo ThinkColour | Supported (via Accessories & Display Manager) |
